Easy-to-use
Zenius makes it easy for you every step of the way! Discover a wealth of advanced features loaded in a contemporary yet compact design.
- Card feeder and output tray located at the front of the printer
- Manual feeder
- Control panel with LEDs
Scalable
Equipped with state-of-the-art printing technologies, the Expert version of Zenius can be upgraded onsite with multiple encoders. These flexible features ensure that you will always be in line with your current and future requirements in plastic card printing.
- Direct access to ports
- Factory ordered or on-site upgradable with additional modules*
- Magnetic and smart card encoders can be combined within the same printer*
Compact, lightweight and silent:
With a low sound level and its amazingly small size, Zenius can be accommodated in virtually any environment, be it a welcome desk, a sales counter, or an office desk. By its really low weight, Zenius is the lightest printer in its category.
Eco-designed
Zenius has earned the coveted ENERGY STAR certification and complies with the reduced energy consumption guidelines from the ErP European Directive
- Standby and Sleep modes
- ENERGY STAR certification
- Compliance with the ErP European Directive
General printer specifications
- Single-sided printing module, edge-to-edge printing
- Color-dye sublimation and monochrome thermal transfer
- 300 dpi print head (11.8 dots/mm)
- 16 MB of RAM
Printing performances
- Color: from 120 to 150 cards per hour
- Monochrome: from 400 to 500 cards per hour
Card management and specifications
- Choice of automated or manual feeding
Evolis High Trust® ribbons®
Maximize the quality and durability of printed cards, the lifespan of your print head and the overall reliability of your printer!
- Automatic detection and setup
- Ribbon embedded in a cassette for ease of use
- Ribbon saver feature for monochrome printing
Display
- LEDs
- Graphic notifications from the printer2 : Empty feeder, cleaning, ”approaching end-of-ribbon” and “end-of-ribbon” warnings
Software
Supplied with the Evolis Premium Suite® for Windows:
- Printer driver
- Evolis Print Center for printer management and setup
- Evolis Printer Manager for two-way notifications 3
- Compatible with Windows™: XP SP3 32/64 ; Vista 32/64, W7 32/64, W8 32/644
Supplied with the eMedia CS Card Designer (30-day free trial to be downloaded from Mediasoft’s website)
Other OS: Mac 10.5 to 10.8, Linux upon request
Warranty
- 2-year warranty (printer and printhead)5 , up to 4 years with optional warranty extension.
| |
| Feeder capacity |
50 cards (0.76 mm – 30 mil) |
| Output tray capacity |
20 cards (0.76 mm – 30 mil) |
| Card thickness |
0.25 to 1 mm (10 to 40 mil), calibration via the gauge |
| Types of cards |
Types of cards : All PVC, Composite PVC cards, PET, RPET, ABS1 and special varnished cards1 |
| Card format |
ISO CR-80 – ISO 7810 (53.98 mm x 85.60 mm – 3.375” x 2.125”) |
| 1 Under specific conditions |
| |
| Ribbon capacity: |
| YMCKO |
300 prints/roll |
| 1/2 YMCKO |
400 prints/roll |
| KO |
600 prints/roll |
| Monochrome ribbon |
up to 1,000 prints/roll (Under specific conditions) |
| Hologram ribbon |
400 prints/roll |
| Interfaces |
USB 1.1 (compatible 2.0)
Ethernet available as an option |
| Size (H x L x W) |
195 mm (7.68”) x 205 mm (8.07") x 310 mm (12.2”) |
| Weight |
3.3 kg (7.3 lbs) |
| |
|
| Sound (evaluated according to the ISO 7779 Standard) |
| Sound pressure level, LpAm, bystander position (YMCKO color mode) |
| When operating |
46dB (A) |
| In sleep mode |
Background noise only |
| Safety |
| Support for Kensington Lock® |
| Data encryption for magnetic encoding (for the ‘Expert’ version or above) |
| Packaging content |
- Printer
- CD-ROM with the printer driver and user manual
- Cleaning kit
- USB cable
- Power supply and cords
|
| Options & accessories |
| Available colors |
Fire Red or Grey Brown |
| Ethernet TCP-IP (for the ‘Expert’ version or above) |
| Encoding options can be combined, factory ordered or upgraded on-site with additional modules (expert version): |
Magnetic stripe encoder, smart card contact station, smart card encoder and contactless smart card encoder. Other encoders available upon request. |
