Pebble4 is designed to cater to all your requirements, be they small runs or bulk personalization of
plastic cards. Pebble4, today, is the ideal solution for any type of application that requires singlesided printing of badges:employee badges, student IDs,access control badges, transport
passes, loyalty cards, payment cards and many more.Thanks to the most advanced
printing engine in the market,Pebble4 delivers high-definition badges within seconds. This
solution benefits from the latest encoding technologies: ISO or JIS2
magnetic tracks, and smart card with contact or contactless (RFID).
These encoding options can be seamlessly combined to personalize multifeatured cards
in a single pass.Pebble4 comes with a very convenient 100-card feeder. Yet, it
can also turn into an elegant overthe-counter display, thanks to the
manual feeding option that lets you print your badges, card by card, for
instant delivery to the holder.Pebble4 comes in a splash of three different translucent colors that
can be interchanged: switch from Fire Red to Jungle Green to Ocean Blue, and make sure
Pebble4 is always in line with your environment or taste.The Pebble4 range of printers
proudly carries the stamp of Evolis’ strong commitment to reliability,and therefore, benefits from
unmatched quality along with apioneering 1-year warranty.Card types • All PVC, Composite PVC cards, PET, ABS 1 and special varnished 1 cards Card format • ISO CR-80 - ISO 7810 (53.98 mm x 85.60 mm - 3.375” x 2.125”) ISO CR-79 (52.10 mm x 83.90 mm - 3.303” x 2.051”) optional
Card thickness • From 0.25 mm (10 mil) to 1 mm (40 mil) Card feeder capacity • 100 cards (0.76 mm - 30 mil), 300 cards (0.25 mm - 10 mil)Card output hopper capacity • 50 cards (0.76 mm - 30 mil), 150 cards (0.25 mm - 10 mil)Printer size • Height: 192 mm (7.55”) - Length: 396 mm (15.59”) - Width: 235 mm (9.25”)Printer weight • 5.9 Kg (13 Lbs)Connections • USB (cable supplied) - Option for Ethernet TCP-IP Electrical • Power supply: 100-240 V AC, 50-60 Hz, 1.8 A - Printer: 24 V DC, 3 AEnvironmental • Min/max operating temperature: 15° / 30° C (59° / 86° F)
Humidity: 20% to 65% non-condensing Min/max storage temperature: -5° / +70° C (23° / 158° F)
Storage humidity: 20% to 70% non-condensing Operating ventilation: free air
GENERAL SPECIFICATIONS
• Color printing module
• 300 dpi print head (11.8 dots/mm)
• USB connection
• Option for Ethernet TCP-IP connection
• 16 MB RAM
• Detachable feeder with a capacity of 100 cards
(0.76 mm - 30 mil)
• Output hopper with a capacity of 50 cards
(0.76 mm - 30 mil)
• 1-Button and 4-LED control panel
• Printer colors: Ocean blue, Fire red or Jungle green
PRINT MODES
• Color dye sublimation and monochrome thermal transfer
• Enhanced color management system
• Edge-to-edge printing
• Integrated ribbon saver for monochrome printing
PRINTING SPEED
Personalization throughput will depend on card design
and printer settings.
• Color (YMCKO): 150 cards/hour
• Monochrome: up to 1000 cards/hour 1
SUPPORTED PLATFORMS
• Windows™ XP, Server 2003 and Vista 32 & 64 bits
• Mac™ OS X v10.2, 10.3 and 10.4
• Linux
SUPPLIED SOFTWARE
• eMedia Card Designer Software for designing and
editing badges
• Compatible with Windows™ XP, Server 2003 and
Vista 32 & 64 bits
• Connection to Microsoft™ Excel databases
RIBBON TYPES
• 2-panel KO black monochrome ribbon - 500 cards/roll
• 5-panel YMCKO color ribbon - 200 cards/roll
• Half-panel YMCKO color ribbon - 400 cards/roll
• Monochrome ribbons - up to 1000 cards/roll
(black, red, green, blue, white, gold and silver)
• Special ribbons:
• Varnish hologram - 350 cards/roll
• Scratch-Off - up to 1000 cards/roll
• BlackWAX monochrome ribbon (for ABS & special
varnished plastic cards) - up to 1000 cards/roll
OPTIONS
• Encoding options (can be combined):
• Magnetic stripe encoder ISO 7811 HiCo/LoCo or JIS2
• Smart contact station - ISO 7816-2
• Smart contact station and encoding unit - PC/SC, EMV 2000-1
• Contactless encoding unit - ISO 14443A, B, ISO 15693,
Mifare, DesFire, HID iCLASS
• Other types upon request
• 100-card additional feeder:
Ocean blue, Fire red or Jungle green
• Manual card feeder:
Ocean blue, Fire red or Jungle green
• Travel case and bag • Cleaning kits
WARRANTY
Use Evolis Genuine products for best performance and
extended lifespan of your printer.
